AB11.D
- 2025-01-17 14:58:15
- 0
技術要求
AB11-D 二極管產品描述峰值電壓:小于等于1000V使用溫度:-40℃~+125℃
額定電流:1A
材質:1、C.R. S.
2、塑膠,阻燃環氧模塑料,易燃性分類94V-0"過電壓保護護環,高電流能力,低正向電壓降·安裝:有正負要求，插入盒前需確認頂部標示;
technicalrequirement
AB11-DD diode product descriptionPeak voltage:less than or equal to1000V0perating temperature:-40℃~+125℃
Rated current:1A
Material:1 C.R.S.
2.Plastic, flame retardant epoxy molding compound, flammabilityclassification 94V-0Dvervoltage protection ring,high current capability,low forward voltagedroDInstallation: There are positive and negative requirements, and the toplabel needs to be confirmed before inserting into the boxj
